128 Item 3D Medical THI Ultrasound Machine For Sale With Convex Probe YR05148

Manufacturer: Kalstein


  • 15 ′ LED display with multilingual function
  • CF + B model simultaneously, PDI, DPDI, TDI, TSI, supports trapezoidal imaging, virtual convex matrix and convex matrix expansion.
  • Anatomy M, Color M mode
  • Pressure rating
  • Complex model image
  • Automatic IMT measurement, automatic endometrial measurement, automatic quality assessment
  • Duplex and triplex PW can be switched freely
  • PW auto-tracking measurements
  • Multiple birth measurements
  • Built-in DICIM 3.0 protocol, can print and send via DICOM 3.0
  • Integrated workstations, databases, imaging reports, fetal development curves, scoring standards, etc. can be inserted.
  • Online care function, instruct the user how to operate in the next step.
  • The printed area is adjustable, which can be images, reports, or images + reports, etc.
  • User rights control, password can be set.
Technical description
Model YR05148
Picture Modes B, 2B, 4B, M, B / M, B / C, B / D, B / C / D

, B / CFM / D, PDI Color, Dual Color,

Simultaneous 2D / Composite Color,

PW, Duplex / Triplex, CFM,

CDE, PD, Directional PD, CD

Physical specifications
Team Size 375mm * 360mm * 75mm
Equipment Weight 3.5 kg
Packing size 490mm × 270mm × 490mm
Packaging Weight 10kg
Connectivity / Media / Peripherals
Transducer Ports two
USB ports two
HDD 64GB (SSD), 120G / 200GB SSD (optional)
Printing area Image, report, Image + report
Ethernet port 2 (100Mb / 1000Mb)
External display VGA, HDMI, etc ..
Printer (Optional) USB Printer, Digital Laser

Printer, B / W Digital Thermal Printer

Digital technology Panoramic imaging technology

Fully digital signal processing technology

Multi-beamforming technology Spot

reduction technology Tissue

harmonic imaging

technology Dynamic tissue optimization technology

Duplex and triplex synchronous display

Directional power Doppler imaging

parameters Imaging parameters

special tissue presets

PW Online Auto Trace


CF + B mode on one screen

Complex model

imaging Automatic IMT measurements

Virtual convex matrix

Trapezoidal imaging

General performance Digital broadband 12288 channels
Beam former reprogrammable
Transmission voltage Adjustable (15 steps)
Beamformer frequency range 1 ~ 40 MHz

Additional information

Weight 10 kg
Dimensions 49 × 27 × 49 cm
