Rotary Evaporator YR02306

Manufacturer: Kalstein


It is suitable for experiment of evaporation, distillation or separation of chemicals. It usually works with water circulating vacuum pump and recirculating chiller as a whole system to meet the production and experimental requirements.

  • Patented technology of double sealing of Teflon(PTFE) AND FV rubber can ensure the negative pressure level.
  • Wide power supply range of main machine from 100V to 240V๏ฝž๏ผŒ50/60Hz.
  • PID controller ensures precise temperature control.
  • Patented designed structure, the tilt angle of the evaporating flask is adjustable.
  • Quick lock button on rotation axis makes it easier to be installed or removed.
  • Motorized lift keeps lifting more smoothly.
  • Synchronous belt drive mechanism can running smoothly, ultra-low noise during rotation process.
  • Individual main machine and water bath design for easy future upgrades.
Technical Specifications
Model YR02306
Rotaion Speed 10~280 rpm
Pressure rise rate of vacuum system <=0.33kPa/min
Temperature Range RT+5~95โ„ƒ
Temperature Stability ยฑ1โ„ƒ
Temperature Control Keypad input, digital display
Speed Control Knob setting, digital display
Lifting Motorized lift
Lifting Distance 150mm
Lifting Speed 10mm/s
Rotary Motor Power 40W
Heating Power 1300W
Condensing Area 0.126m2
Evaporating Flask 500ml, 1000ml
Receiving Flask 1000ml
Vacuum Sealing Double sealing rings made of Teflon+ Viton materials
Water Bath size ยทCapacity 250ร—130mmยท6.5L
Evaporating Speed
Water 23ml/min
Ethanol 26ml/min
Power Supply
Main Machine 100V~240V, 50/60Hz
Water Bath 110V~, 60Hz or 220-240V~, 50/60Hz
Ambient temperature 5~35โ„ƒ
Environment Relative Humidity <=70
Protection Class of Shell IP20
Pollution Prevention Grade Grade 2
Dimensions 595W*390D*680Hmm
Net Weight
Main Machine 10KG
Water Bath 3.9KG
The Rotary Evaporator model YR02306 does not include vacuum pump or recirculator, these can be included as required, the models would be YR02301 (Recirculator) + YR05158 (Vacuum Pump), for the complete set.

Additional information

Weight 31 kg
Dimensions 58 × 72 × 61 cm
