Heating Mantle / (Stirrer)
Heating blankets are useful in microbial fermentation processes, allowing researchers to control the fermentation medium properly without having to worry about uncontrollable temperature variation, maximizing success in the production of any microbial product.
Another important application of heating blankets is for chemical synthesis processes. These heating blankets are especially useful for accelerating the process of chemical reaction, allowing the reaction heat to be reached more quickly. This means that the reaction time can be significantly reduced without worrying about the cooling effects that occur during experiments.
In short, these equipments provide a uniform temperature for experiments, allowing a great saving of time and effort to the researcher. Therefore, it is evident that heating blankets are fundamental in the development of any laboratory experiment.
Types of Heating Bed (Agitators) a Laboratory may need
Heating Mantle YR05021 // YR05036
Digital type single position mantles are with outer sensor, multi position mantles are with inner sensor, outer...
Heating Mantle YR05039 // YR05048
YR heating mantle are the most widely used heating mantle in laboratories,Once shaping shell is made of cold ...
Heating Mantle YR05055 // YR05058
YR05055 and YR05058 multi heating mantles are designed for repetitive extraction (Kjeldahl, Soxhlet and other ...
Multi Heating Mantle YR05049 // YR05054
YR multi heating mantles are designed for repetitive extraction (Kjeldahl, Soxhlet and other extraction procedures)...
Our Best Selling Heating Mantle (Shaker)
YR heating mantle are the most widely used heating mantle in laboratories.
- Once shaping shell is made of cold rolled steel sheet with surface spraying treatment
- nichrome heating wire, litter warming up time, long service life
- Easy operation, wide application
- Precise PID Temperature control meets high accuracy experiment needs
- Digital type single position mantles are with outer sensor, multi position mantles are with inner sensor, outer sensor optional
| Type | Analog | ||||||
| Model | YR05021 | YR05022 | YR05023 | YR05024 | YR05025 | YR05026 | YR05027 |
| Capacity (ml) | 100 | 250 | 500 | 1 000 | 2 000 | 3 000 | 5 000 |
| Voltage (V) | 200 – 240V / 50 – 60Hz or 100 – 120V / 50 – 60Hz | ||||||
| Max Use Temperature (°C) | 380 | ||||||
| Power (W) | 100 | 150 | 250 | 350 | 450 | 600 | 800 |
| Working Size | Continuous | ||||||
| Exterior Size (mm) | Ø200×160 | Ø260×200 | Ø300×230 | Ø340×245 | Ø350×250 | ||
| Packing Size (mm) | 230 x 230 x 170 | 290x290x220 | 330x330x250 | 365x365x295 | 390x390x310 | ||
| Net Weight (Kg) | 2.5 | 4 | 5 | 7.5 | 8.5 | ||
| Gross Weight (Kg) | 2.8 | 6 | 7 | 8 | 9.2 | ||
| Type | Digital | ||||||
| Model | YR05030 | YR05031 | YR05032 | YR05033 | YR05034 | YR05035 | YR05036 |
| Capacity (ml) | 100 | 250 | 500 | 1 000 | 2 000 | 3 000 | 5 000 |
| Voltage (V) | 200 – 240V / 50 – 60Hz or 100 _ 120V / 50 – 60 Hz | ||||||
| Max Use Temperature (°C) | 380 | ||||||
| Power (W) | 100 | 150 | 250 | 350 | 450 | 600 | 800 |
| Working Size | Continuous | ||||||
| Exterior Size (mm) | Ø200 x 160 | Ø260×200 | Ø300×230 | Ø340×245 | Ø350×250 | ||
| Packing Size (mm) | 230 x 230 x 170 | 290x290x220 | 330x330x250 | 365x365x295 | 390x390x310 | ||
| Net Weight (Kg) | 2.5 | 4 | 5 | 7.5 | 8.5 | ||
| Gross Weight (Kg) | 2.8 | 6 | 7 | 8 | 9.2 | ||
Analysis of the best Heating Mantle for your Laboratory
Heating mantle
The heating blanket is equipment used in laboratories to heat in a stable and uniform way, samples...
Types of warming blankets
The heating blanket is a laboratory equipment used mainly in chemistry and biology laboratories, whose main ...
What is a warming blanket?
The heating blanket is a piece of equipment used in laboratories to supply a certain stable temperature in...
How are they used?
The heating blanket is a laboratory equipment that generates heat in an efficient, environmentally friendly...
Catalog of models of Heaters (Agitators) on offer
Guides to becoming an expert in Heating Mats (Agitators)
Why is it necessary to use Heaters in the Laboratory?
One of the main equipment used in laboratories is the heating cloth, a device that ensures injury prevention and temperature...
The Importance of Heating Blankets in the Laboratory
Heating blankets or agitators are essential equipment for many laboratory applications. These heating blankets...
Heating blankets and water bath: differences
Heating blankets and water baths are laboratory equipment used in different areas and each one has its own distinctive...
How a laboratory heating blanket works. What are they used for?
This equipment allows to apply heat uniformly, avoiding possible risks in chemistry and biology laboratories; a heating blanket comes equipped with a flexible and insulated heating device, which allows containers to be positioned directly on them...
Videos of Heaters Brand KALSTEIN
In this section you can find, our Heating Blocks (Agitators) in operation, packaged, receiving service, etc..
Heating beds (Shakers) in operation
One of the main equipment used in laboratories is the heating cloth, a device that ensures injury prevention and temperature regulation for the safety of workers and products in the laboratory. Heating blankets are used to heat liquids, as the temperature must be controlled to prevent damage to components, products and workers. The heating blanket is also used to regulate the temperature of liquids with a very high level of precision.
The importance of using heating cloths in the lab is that they provide safety. In the event of an electric shock, the heating cloths offer greater safety by insulating the fabric from the electrical resistance. This will reduce the likelihood that components or products will be damaged by excessive temperature rise and prevent electrical shock injuries.
Frequently Asked Questions about Heating Blocks (Agitators)
How to know the prices of Heating Blocks (Agitators)?
To know the price of the Heating Blocks (Agitators) we invite you to send us an email with your request through the contact form.
What are the delivery times of the Heating Blocks (Agitators)?
- If the equipment of your interest is in stock or if it must be manufactured.
- The type of freight you have chosen, this may be; air or sea.
How to make a purchase of Heating Blocks (Agitators)?
- By email: [email protected]
- By telephone: +33 (0) 1 78 95 87 02
- E-commerce: Via Kalstein's official website in your country.
How does the warranty work?
Can I request a quote online?
Of course, you can request a quote for the Kalstein team of your interest, directly from our official website. Once you have identified your preferred model, click HERE
