Description
- Smart and compact design, light and easy to move.
- 7 inches LCD color touch screen, stand-alone system and no need PC.
- User-friendly operating system, module Ul design, simple and clear.
- Long-life Xenon lamp, no warm-up time.
- Storage by USB, simple to retrieve test data.
- Multi-functions: Nucleic acid , Protein, Kinetics, spectrum scanning, end-point and OD600 measurement.
- No need to dilute sample, luL to 2uL is enough.
- High resolution CCD detector, fast measurement (5 seconds), high repeatability and accuracy.
- Available to upgrade software by USB, low maintenance cost.
- Two USB ports for data output and outer tools like mouse and keyboard.
Technical Specifications:
| Model | YR06033 |
| Generation Specification | |
| Light Source | Xenon Lamp |
| Detector | CCD (2048 Pixels) |
| Wavelength Range | 190-1100nm |
| Wavelength Accuracy | ± 1nm |
| Spectral Resolution | 0.3nm |
| Dimension | 220*280*220 mm |
| Weight | 3kg |
| Power Supply | 100-240V, 50-60Hz |
| Power Consumption | 80-100W |
| Nano Volume Specification | |
| Absorbance Precision | 1%@100ng/µI |
| Absorbance Range | 0-200Abs (10nm equivalent) |
| Detection Limit | 2ng/µI (dsDNA) |
| Max. Concentration | 15000ng/µI (dsDNA) |
| Measurement Time | 5s |
| Min. Sample Volume | 1µI |
| Path Length | 0.01-1.2mm (auto-ranging) |
| Cuvette Specification | |
| Beam Height | 8.5mm |
| Absorbance Range | 0.002-2.0 Abs |
| Measurement Time | 3s |
| Path Length | 10mm |
