Veterinary Portable Surgery Diode Laser Systems YR06133 – YR06134



The new portable surgery diode laser system is the best value on the market today. Small size body case with 15W power this mini suregery laser system has 810nm and 980nm dual-wavelengths, 810nm/980nm with pilot beam 300mW for choice, it can be used in the continuous as well as pulsed mode with a contact or non-contact handpiece.

  • Compact design makes it small in size and light in weight, easy to transport;
  • Highly integrated and modular design;
  • New design inside to make maintenance easy and low cost;
  • Advanced software with presetting protocols to be manually customized by operator;
  • Built-in power meter can test the power in the software by user;
  • Output power calibration at the end of fiber to make the maintenance easy and low cost;
  • Adopt air cooling system guarantee stable performance and long life time.
Technical Specifications
Model YR06133 YR06134
Wavelength 810nm/980nm 810nm+980nm
Maximum Power 15W 15W+15W
Operation Mode CW,Single or Repeat Pulse
Pulse Duration 25uS-10S
Repetition Rate 0.05Hz-20KHz
Pilot Beam Red Diode Laser of 635nm, Power
Control Mode Touch Screen, 8” True Color
Dimension 315(H)*215(W)*245(L)mm
Life time Over 10000 HRS

Additional information

Weight 17 kg
Dimensions 58 × 42 × 50 cm

YR06133, YR06134
